Suyash Dubey | Posted on | 2 min Read

In the year 2028, there will be around 7.8 Billion mobile users which accounts for 70% of the world population. More mobile users mean more apps and more competition and to lead the competition we need to make sure that our app is flawless. If nearly half of the bugs in your mobile app are discovered by the users, your app’s ratings are going to decline and so are the downloads. This is why the right choice of mobile app testing techniques must be followed in the decision-making process.

Mobile App Testing Strategies

Today, the mobile app market is highly competitive. To be better every day and survive for long, the QA team has to follow a mix of plans that would be responsible for taking the right testing decisions. The testers have to formulate testing strategies to face every situation fearlessly and immaculately. Mobile apps have to be perfect before reaching to the end users so there have to be certain decisions to be taken regarding the testing plan. The following model of mobile app testing plans can be considered for better execution.

In the planning Stage, decisions like Selection of Device matrix, Test Infrastructure (In-house vs. Cloud, Simulator vs. Real device), Testing scope, Testing Tools, Automation (Framework/Tool) are taken. Since it is the first stage, it is the most important one as all the further stages would depend on these decisions. In the next stage which is execution and review, decisions regarding Test Case Design, Testing of user stories, testing types as per Sprint Objective, Progressive Automation, Regression Testing, Review and course correction are taken.

We are going to discuss the planning stage aspects more elaborately

Device Matrix:

It is an important factor, choosing the device as per your target audience’s behavior matters in decisions regarding resting. There are different approaches to the selection of the device matrix.

Approach 1- Selection of Devices based on market research.

Determine the set of devices with your target operating System that will have the highest occurrence of accessing your application by using app purchase data and analytics. For Example- if you support both Android and iOS, and your application will be used across millions of Samsung, Google Nexus and Moto G devices but only thousands of iPhones, you prioritize testing on the Google Nexus and Moto G above the iPhone device. So, this test plan will consist of testing on devices which are prioritized by your market analysis.

Approach 2: Categorize the devices based on Key mobile aspects

This approach highlights the categorization of the devices based on certain mobile aspects which can be considered in formulating the testing strategy. The categorization goes as:
Mobile device categorisation

Test infrastructure

This is another element of the planning stage. This focuses on Strategizing on the Infrastructure components like hardware, software, and network which are an integral part of test infrastructure. It ensures that the applications are managed in a controlled way.

Real device, Emulators or Mobile cloud-Where to test?

Choosing the right platform to test as per the testing needs is very important i.e whether to test on the Real device or an emulator or on the cloud

Real Devices

Testing on a real device is anytime more reliable than testing on a simulator. The results are accurate as real-time testing takes place on the device in a live environment. It carries its own disadvantages as it is a costly affair and not all the organizations are able to afford a complete real device laboratory of their own.

Pros:

Reliable- Testing on Real devices always gives you an accurate result

Live Environment- Testing on real devices enables you to test your application on the actual environment on which your target audience working on. You can test your application with different network technologies like HSPDA, UMTS, LTE, Wi-Fi, etc.

User experience- Testing on Real devices is the only way to test your Real-time User experience. It cannot be tested through Emulators or devices Available on Cloud.

Cons:
Maintaining the matrix- You cannot maintain such a huge matrix of mobile devices in your own test lab.
Maintenance- Maintaining these physical devices is a big challenge for organizations.
Network providers- There are more than 400 network providers all over the world. Covering all these network providers in their own test lab is impossible.
Locations- You cannot test how your application behaves when it is used in different locations.

Emulators

The emulator is another option to test mobile apps. These are free, open source and can be easily connected with the IDE for testing. The emulator simulates the real device environment and certain types of testing can be run on it easily. However, we cannot say that the results of emulators are as good as those of real devices. It is slower and cannot test issues like network connection, overheating, battery behavior, etc.

Pros:

Price- Mobile emulators are completely free and are provided as part of the SDK on every new OS release.

Fast- As Emulators are available on the local machine so they run faster and with less latency than Real devices connected to a local network or devices available on the cloud.

Cons:

The wrong impression- Even if you have executed all test cases on emulators, you cannot be 100 % sure it will actually work in the real environment.

Testing Gestures- Gestures like Pinching, Swipe or drag, long press using the mouse on simulators are different in using these gestures on real devices. We cannot test these functionalities on emulators.
Can’t test Network Interoperability- With the help of Simulators you cannot test your application with different network technologies. Like HSPDA, UMTS, LTE, Wi-Fi, etc.

Testing on Mobile Cloud

Mobile cloud testing can overcome the cost challenges like purchasing and maintaining mobile devices. It has all different sets of device types are available in the cloud to test, deploy and manage mobile applications. The tests run virtually with the benefit of choosing the right type device-OS combinations. Privacy, security, and dependency on the internet can be a challenge in this case but it has many benefits that can cater to different testing scenarios.
Mobile cloud

The organization can choose the right mix of above-mentioned platforms as every platform carries its own advantages and disadvantages. Sometimes a combination of real and emulators is preferred and sometimes all three can be considered as per the testing strategy.

Pros:

Devices Availability- Availability of Devices and network providers is a big gain for cloud users.
Maintenance- When you are using cloud services. Forget about maintenance. These providers take responsibility for maintaining these devices.
Pay per use- You don’t need to buy a device. You only have to pay for the duration you use that device.

Parallel Execution- You can test your complete test suite on multiple devices.

Cons:
Cost- Some providers are a bit costly

Automation Tools for Mobile App Testing on Android and iOS

Nowadays, there are so many automation tools available in the market. Some are expensive and some are freely available in the market. Every tool has its own pros and cons. Choosing the right tool for testing would reduce the QA team effort providing seamless performance at the same time. We will discuss the best mobile app testing automation tools for iOS and Android platforms in 2018.

1. Appium: It is one of the preferred MAT tools by testers. It is open source and free tool available for Android and iOS. It automates any mobile app across many languages and testing frameworks like TestNG. It supports programming languages like Java, C# and other Webdriver languages. It provides access to complete back end APIs and database of the test codes.
Top Features:
-Appium supports Safari on Ios and Other browsers on Android
-Many Webdriver compatible languages can be used such as Java, Objective-C, JavaScript to write test cases
-Support languages like Ruby, Java, PHP, Node, Python.

2. Robotium: It is a free Android UI testing tool. It supports in writing powerful black box test cases for Android Applications. It supports Android version 1.6 and above. The tests are written in Java language and basically, Robotium contains a library of unit tests. Apart from this, Robotium takes a little more effort in preparing tests, one must work with program source code to automate tests. Robotium does not have play record and screenshot function.

Top Features:
-The tests can be created with minimum knowledge of the project
-Numerous android exercises can be executed simultaneously.
-Syncronises easily with Ant or Maven to run tests.

3. Calabash: It is an open source MAT tool allowing testers to write and execute tests for Android and iOS. Its libraries enable the test codes to interact with native and hybrid apps. It supports cucumber framework which makes it understandable to non-tech staff. It can be configured for Android and Ios devices. It works well with languages like Ruby, Java, .NET, Flex and many others. It runs automated functional testing for Android and ios. It is a framework that is maintained by Xamarin and Calabash.

4. Espresso: It is a mobile app testing automation tool for Android. It allows writing precise and reliable Android UI tests. It is a tool targeted for developers who believer automated testing is an important part of CI CD process. Espresso framework is provided by the Android X Test and it provides APIs for writing UI tests to simulate user interactions on the target app. Espresso tests can run on Android 2.33 and above. Provides automatic sync of test actions with the app UI.

5. Selendroid: An open source automation framework which drives off the UI of Android native, hybrid and mobile web application. A powerful testing tool that can be used on emulators and real devices. And because it still reuses the existing infrastructure for web, you can write tests using the Selenium 2 client APIs.

6. Frank: Is an open source automation testing tool for the only iOS with combined features of cucumber and JSON. The app code needs not to be modified in this tool. It includes Symboite live app inspector tool and allows to write structured acceptance tests. It is tough to use directly on the device but is flexible for web and native apps. It can run test both on simulator and device. It shows the app in action by showing its recorded video of test runs.

Above are a few promising, popular and most commonly used and mobile app testing automation tools. Choice of tools certainly resolves many testing-related problems faster and efficiently. Implementing these tools requires skill and experience and so an organization needs to have a proper testing team in place to make all of this possible.
Related Articles:

What is Application Performance Monitoring (APM)?



Application Performance Monitoring (APM) involves employing various strategies and tools to ensure the efficient operation of business applications. These apps need to meet the performance, reliability, and user experience requirements set by stakeholders, such as employees, clients, and partners.



Mobile Application Performance Monitoring is a part of the broader term Application Performance Management, which encompasses all aspects of managing an application’s performance, while APM focuses on monitoring an application’s performance. In simple terms, monitoring is an integral part of management.



What is the purpose of APM?

The main goal of Application Performance Monitoring (APM) is to maintain an application’s optimal performance and smooth operation. It enables linking application performance to business results, detecting and correcting mistakes before they impact end-users, and minimizing mean time to repair, aiding organizations in maintaining business continuity and enhancing customer satisfaction



Why is APM crucial?



Application Performance Monitoring (APM) is important because of all the advantages it offers to a business in terms of operational effectiveness, brand recognition, and long-term cost savings.



By enabling front-end monitoring, managing the user experience, back-end monitoring of the services and dependencies used by the app, and infrastructure monitoring, APM offers improved collaboration and coordination in the application delivery process. This promotes seamless and transparent application delivery and the elimination of silos.



APM safeguards the organization’s reputation and brand image by ensuring applications are reliable and accessible. Poor application performance can lead to user dissatisfaction, lower application utilization, slower adoption, and decreased revenue. APM is essential to maintaining a good reputation and ensuring application success.



App Performance while conducting Manual Tests

The performance of an app can be viewed real-time while conducting functional tests. You can simply select the application installed on the device from the Tools section to view a graph of Memory and CPU usage, with the packets/bytes consumed in the Data Usage.

application performance monitoring
application performance monitoring

All information captured during a app testing session is gathered by the platform and stored in a secure location to be used later. When a tester completes his testing session using a device, the performance related information can be found in the Cloud Drive.



Battery Consumption

The Battery Consumption graph indicates Battery consumption by Device, Battery consumption by Application and Battery consumption in %.

Perf_Battery_Consumption

 CPU Consumption

The CPU consumption of an App is plotted as CPU consumption in percentage against Time Duration in seconds.

Perf_CPU_Consumption



Memory Consumption

The CPU consumption of an App is plotted as Memory consumption in ‘Mb’ against Time Duration in seconds.

Perf_Mem_Consumption

How pCloudy can help you?



Mobile application testing does not stop when all the functional tests pass. Testing the application performance monitoring is a critical step before releasing it.



pCloudy helps you with performance profiling of your mobile apps. You can view the CPU usage, Memory usage, Data usage and Battery consumption while performing a series of actions on the app. The Real time app performance monitoring feature helps you to keep track of the app’s performance while conducting manual tests. You can even check the performance consistency of the app by running automation test suites in parallel on multiple devices and by also simulating different network environments.



Priyanka Charak | Posted on | 2 min Read

Why Appium is The Best?



With Appium creating a buzz in enterprise mobility, mobility teams are still finding ways to successfully automate tests leveraging Appium. Appium being an open source tool is the perfect choice for automating native, mobile web and hybrid applications on their respective platforms.

Let us now see the major factors behind Appium being the best choice for mobile automation tool:



Test App
An impressive expression by Appium.io showing why to choose Appium



1. Use of standard API: Appium is widely popular because modification of codes or a recompilation of your app is not required as it uses the standard API in all the platforms. Appium makes it effortless to create your tests against iOS and Android platforms with same API. But, separate iOS and Android scripts are still needed as the UI elements vary on both the platforms.



2. Use any WebDriver compatible language: Appium gives the freedom from getting locked into a particular language or framework to write and run the tests. Any WebDriver compatible language like Perl with Selenium WebDriver API, Java, PHP, C#, Python, Ruby, Javascript with Node.js can be used for writing the tests.



3. Testing Framework of Choice: Appium gives flexibility to mobility teams to use testing framework of their choice. Earlier, tests could only be written through Javascript using the UI Automation of library for Apple or Java based tests could only be written through UI Automator of Google. Appium completely changed this scenario.



4. Cross-platform test automation: Having the capabilities to test on both Android and iOS devices makes it the best cross-platform mobile app test automation tool. In order to interact with Android and iOS with Selenium WebDriver, Appium uses the JSON wire protocol. Appium makes use of the libraries provided by Apple with the help of an application called Instruments to automate iOS apps. In newer versions of iOS after v9.3, the Instruments api has been deprecated and now use XCUITest framework.
The method is similar in Android also where Appium proxies the automation command to the UIAutomator test case running on the device. Android has a native UI automation framework called UIAutomator which supports running JUnit test cases from the command line directly into the device.



5. Open Source: Being an open source testing framework is one of the biggest advantages of Appium as it supports Simulators, Emulators, real devices, and of course, native, hybrid and web application testing of iOS and Android. Appium having a large and thriving open community makes it easier for new automation engineers to clarify their doubts.



You can instigate test scripts created from Appium libraries locally, on a session reserved by the Cloud, for any iOS or Android device. Appium integrates with continuous integration servers to ensure better results and drives GUI-related widgets and controls, allowing the same scripts to run for different software versions of various apps. Appium can automate native, web and hybrid mobile apps, and you can test on a real device, a simulator, or an emulator. It also supports Safari on iOS and Chrome Mozilla or any built-in ‘Browser’ app on Android.
There are many automation tools for mobile application testing. Testers usually choose Appium as the best mobile testing tool. Mobile automation testing tools comparison can be done on the basis of language support and continuous integration. The most common automation testing tools used for mobile application testing are Appium, Robotium, and Calabash. If you are looking for iOS app automation testing tools then Appium and Calabash can do the job for you.



Here is tabular representation for you to understand Appium’s compatibility with different features and tools.



Appium Automation Testing Tools



Why mobile device cloud with built-in Appium support?



Teams who are getting started with Automation or are considering Appium as an option, must explore an alternative to go for a mobile device cloud with built-in Appium.



A mobile device cloud not only assists in managing and sharing devices, but also helps in streamlining automated testing and continuous delivery processes. A mobile device cloud with built-in Appium makes it easy for teams to get started with automation and scale up later. Furthermore, it will give additional cushion against any sort of roadblock that might occur while using an open-source platform for tests. Let’s have a look at some of the benefits of having a built-in Appium support on a mobile device cloud:



  • Supports parallel testing on multiple devices
  • Reduces the complexity of test frameworks
  • Creation of appium scripts become easy
  • Streamlines the CI/CD process



At pCloudy, we are dedicated towards helping enterprise mobility teams make the process of mobile development, testing and device sharing seamless and faster by integrating it with cutting edge tools like Appium. Read this blog to get a comprehensive analysis sheet to quickly choose which open-source test automation tool will be right for your automation testing.



Sign up on pCloudy and automate your tests using best open source automation tool for faster and better delivery of apps.

For more information check out this video:

Suyash Dubey | Posted on | 2 min Read

Types of Testing

Since there are many players in the mobile app market, the competition is endless. To beat the heat and to keep providing an enhanced mobile app experience to the users, the app needs to be constantly updated with the changes happening and for doing this, there are different types of testing techniques. Let us have an insight into the types of testing methods.

1. Compatibility Testing

Compatibility testing is a critical QA task. It assures that a given application works as intended with selected operating systems, selected devices with different screen sizes resolutions, and internal hardware (memory size, processor speed, and button/input differences). It defines the feasible compatibility combinations of devices and interfaces for a specific testing assignment, in concurrence with the customer’s requirement.

Want to test your Mobile App?

Join pCloudy Platform!

Signup for Free



Compatibility Factors:

There are different factors that play a very significant role in mobile compatibility testing strategy. Mobile operating systems and their supported versions, mobile devices developed by different manufacturers, different device screen sizes with different resolutions and internal hardware including different input types, processor speeds and memory size of devices.

4
Let’s develop a test strategy for compatibility testing. The first step is to identify the Operating systems and devices based on key factors described in the previous slide. Once you identified the devices based on different compatibility factors you need to set up your environment for testing. You can either set up your internal test lab or you can go for external cloud providers like pCloudy. Now, the next step is to execute your test cases on a defined set of environment. Report the defects to appear while testing and report these defects to your development team.

The main purpose of compatibility testing is to ensure whether different software is compatible with different configurations and whether the application is compatible with the client’s environment.

2. Installation Testing

Mobile phones come with different types of mobile apps like Native and Web and Hybrid. Installation testing is a type of testing that is done at the initial stage of mobile app life span or maybe it is the first impression on the users, in other words. Installation testing checks whether the mobile app installs, uninstalls and updates properly without any interruption.

Want to test your Mobile App?

Join pCloudy Platform!

Signup for Free



Installation Testing Factors:

There are some of the factors that play a significant role in installation testing of an application. Factors like which platforms and operating systems supported by the application and how they will be distributed whether it is directly available in the app store or are going to get the installable files on mail itself or is it available on an app distribution platform and can be accessed through public URL. The user behavior regarding installation changes from person to person. For eg: the developer may install the app (By using ADB install command) and a different user might directly install it from the app store or public URL.

Important points to be noted in Installation Testing:

Some of the common checkpoints which can be converted to standard test cases are:

  • Installing the app in phone memory.
  • Installing the app in phone memory is full.
  • Installing the app on an external SD card.
  • Installing the app on an external SD card is full.
  • Check the memory space after installing. It should not occupy more than promised.
  • Check if it is releasing the space after removing

Another part of the installation and uninstallation testing is the testing of patches/updates
These are the common situation when we need to test app after updates.

Check for updates:

  • Can I download an update?
  • Can I update the app when there are multiple updates available?
  • What happens if I don’t update?



When App is upgraded:

  • Check that the user is still logged in
  • Check that data is still the same
  • Backward compatibility:-Check that database changes will not affect the current data.
  • Test the update from an older version to the current version



When OS is upgraded:

  • Check the app compatibility.
  • App updated gracefully without a crash.



3. Interruption Testing

Interrupt testing is a process to replicate abrupt (Unexpected) interrupt to the application. It is done to understand how the app behaves under certain interruptions before resuming to its original state. This can be achieved in various ways and techniques depending on the application under test.

Following are some Common Interrupts:

1. A phone call when the application is running or is in background
2. Battery removal when the application is running or is in the background, battery high, battery low, incoming call or SMS
3. Plugged in or out of charging
4. Device shut down
5. OS upgrade
6. Network loss and restoration, etc.

Some specific scenarios for an application using a network:

1. Connect to the network but remove LAN connection from the router so the device can sense wifi state on the device but cannot connect to the internet
2. Connection via VPN and VPN disconnected

Scenario for Application using services:

1. Kill service by clicking on the recent button and swiping the application right to kill app and services
2. Kill app using third-party App killer
3. Kill specific services from Settings->Manage Applications
4. Scenarios for Application Linked to account Manager
Remove account from Settings->Account Manager

Incoming and Outgoing SMS and MMS:

An application is running in your mobile and you send an SMS/MMS from another mobile to your mobile. In this situation, SMS/MMS notification should display for a while and then close and the application should continue to run.

Incoming and Outgoing calls:

You are in a login page trying to log in and you have just pressed the submit button that will take you to the application home page. This is a transition period because loading is happening.If we receive a call during this time then the application should not end abruptly or crash.

Battery Removal:

If the application is running, remove the battery of your mobile and it will shut down. After rebooting the mobile, run the application again, it should run smoothly and without a crash.

Data Cable Insertion and Removal:

When the application is running, connect the USB Cable, the system should display “USB Connection Screen” and if the user returns to the application then the application should not crash or end abruptly

Interruption Testing Strategy

Let’s prepare a test strategy to test interruption testing:
The first step in this process is to decide the critical interrupts based on your application components and architecture. For example, if your application is using GPS include common interrupts related to GPS. Let’s Include two type of interrupts:

Application specific interrupts:

Prepare your test cases and try to fit theses interruption test cases with state of the application. For example, interrupt your Network while performing payment.

Interrupt testing process:

1

List of common Interrupts:

Phone calls, Text messages, App notifications, Battery Warning, Forced updates, Voicemail, Shaking the Phone, Different Gestures, Switching between apps, Locking and unlocking the screen, Changing the orientation, Music playing while using the app, Out of memory (general performance interruptions), Data app interruptions (What Sapp, Viber, Tango), Audio interrupts from multiple sources (iPod, Media player, Other audio apps), phone in standby mode, switch the network to plane mode.

Tools to test interruption Testing:

Use tools like Joule Unit (Android), On iOS use the Energy Usage Function of Instruments, Monkey for Android to stress test your app and see the handling of the interrupts, UI Auto Monkey for iOS

Scenario

A) Once the user connects the mobile earphone jack with Nokia Lumia and starts music Player.
B) Now when the user resumes the application the cart gets empty.

4. Localization Testing

This type of testing is a technique in which we check whether the mobile app adheres to the local cultural settings, customizing the apps according to target country and language and also according to the linguistic aspects. Localization is also known as “L10N” as there are 10 characters between L & N. For eg: Chinese language-search engine offered by Baidu beats Google in China. Baidu does better than Google because it looks and feels fully native to the Chinese speaking audience.

Also, regional language speakers can’t get many games in their own language, so they turn to race games, which are easy to understand. We must have noticed in these examples, language is the common issue. Apart from Translation there are different other elements in the localization, like Usage of proper Time zone, local formats of dates, addresses and phone numbers, Design and layout to fit translated text, Converting to local requirements (such as currencies and units of measure), Adapting graphics to target markets, Modifying content to suit the tastes and consumption habits of other markets, Addressing local regulations and legal requirements.

Why should we localize?

Localization is important in order to understand the cultural and linguistic aspects of a particular region. While testing, testers keep repeating the tests to check typographical, linguistic errors, cultural appropriateness of the UI, etc. Research says:
1.  56.2 percent of consumers say that the ability to obtain information in their own language is more important than price. (Common Sense Advisory, Can’t Read, Won’t Buy: Why Language Matters on Global Websites, 2006)
2.  74 percent of multinational enterprises believe it is either important or most important to achieve increased revenues from global operations. (California State University at Chico, 2007.
3.  95 percent of Chinese online consumers indicate a greater comfort level with websites in their language. (Forrester Research, Translation and Localization of Retail Web Sites, 2009)
4.   A critical success factor for cross-border merger and acquisition deals is the ability to communicate information clearly and accurately in multiple languages. (Merrill Corporation, How to do Better Multinational M&A Deals, 2008)

Types of Localization Testing:

In the localization testing, validating whether a mobile app is capable of performing given a geographical location, in particular, is found out. It includes four major types of testing like linguistic, culture, cosmetic, and functional tests.
1. Linguistic testing– ensures that the UI text appears in the congregation with the language and is not mistranslated or misapplied. This requires language skill and knowledge of the product. Mistranslation, irrelevant usage of the language are few of the errors in this.

2. Cultural Testing– Few words may imply different meanings in different cultures. So, this has to be translated properly in relation to the target culture.

3. Cosmetic Testing– For easy understanding, let us use this scenario. For eg. In the apps used in Afghanistan, the text will be in Arabic and will start from right to left unlike other languages like English, French that are read from Left to right.

4. Functional Testing– In this testing, testers follow prescribed test scripts to run through all aspects of the product to make sure it functions as designed in a localized environment. Often functional testing includes verification that the localized product is compatible with various operating systems and third-party products. Functional testing generally requires a good knowledge of the target language and total familiarity with the product. Some of the major Functional testing problems may include– Incorrect or missing UI elements, graphics, and windows, Incorrect error messages, Localization bugs that may cause software crashes, Errors generated by installing the localized software on a localized OS.

5. Performance Testing

Performance testing is to test the performance of the mobile application in expected workload scenarios and to eliminate the performance hurdles. It checks whether the response of the app is quick, the ability of the app to tale load, and app stability in those load situations. Performance is very critical because if the app is malfunctioning, it is more possible that the user might uninstall the app and might shift to a competitor’s app which is better.

The three main pillars of Mobile app performance testing are:

Device Performance

App start-up time is the most critical performance parameter from the user’s point of view. It shouldn’t take more than 2 seconds for the app’s first screen to pop up after the user taps on the app’s icon. Battery time is the second most important issue. Some apps consume a high amount of battery life. Excessive resource usage creates a burden on the processor and the phone heats up. In some cases, it is observed that the new app installed uses the same amount of battery as the OS. If more features are added in the app its memory consumption also increases. This is why memory consumption should be checked while testing the app.

Network Performance

The app needs to be tested on different mobile networks and network properties. If there is packet loss then the app should generate alerts or resend the request for the information. Jitters or delay in receiving information

Server/API Performance

Performance is directly proportional to the response time from the Server. In this, tests are run to check how efficient the app is to handle data transfers from the server and how quickly and in what format the data is transported by the app. The number of API calls generated by apps should be lesser and how and where the data is saved in the ‘server down’ case is all that is tested here.

Mobile app testing tools make it easier for the testers to identify and rectify any error that comes up. For different OS there are a different set of Mobile app tools. For Android, we can use Robotium and Monkey Runner and for IOS we can use Automator.

6. Usability Testing

Usability testing is a type of testing which is performed to check how user-friendly the mobile application is in terms of the navigation, ease to use the app, flexible app controls, etc. It is also known as user experience testing.
What matters in Usability Testing?

Workflow: To understand, below image represents the workflow of how the user reaches its goal while navigating through the app controls.
3
We must understand what the user needs to do in order to use the app’s functionality. If the workflow was overlong and included repetitive actions It may annoy the user while performing the task.
Design and Layout: Good layout and design allow a user to easily complete tasks. An app need not offer so many features or content that the app is difficult to navigate. A friendly app has a design that allows less user text entry, helps differentiation between the selected items, finger-sized targets, should provide intuitive hints to texts, etc.

The response time of the application: It is one of the key factors. This means how long the user takes to complete a task. Often long delays while the app interacts with the server hinders the user experience standards.

The emotional state of users: Emotional state of user measures the user’s motivation to use the app. The apps should be smart enough to understand what the users want and how to engage them, this can be achieved by usability testing.

Usability Testing Strategy:

2
The first step is to identify users who match your expected audience. Watch and listen to them as they use your products. You can use video and audio recording equipment for archiving test sessions, in case later review is needed. However, our primary tool is taking notes with paper and pencil! This is still the fastest way we have found to get information quickly to developers and designers. You have your data. You now need to organize and analyze it. How the results are absorbed as a report in order to be useful for product changes.

Tools and techniques for usability testing

1. Mr. Tappy: It is a tool set up to capture how users interact with the apps naturally. The user data so generated could be used for better user experience.

2. Paper Prototyping: It is a technique that consists of creating hand drawings of user interfaces in order to enable them to be rapidly designed, simulated and tested. As simple as this technique may look like, it has been effectively used since the 1980s and is likely to continue to be used with a guaranteed degree of success for many more years to come.

3. Magitest: It allows you to perform mobile user testing of native apps and websites. Captures the participant’s voice and facial expressions during the session. Here the users complete the tasks you specify and allows to listen to them speak their thoughts aloud as they interact with your mobile app.

4. Reflector: This app allows us to see the iPad, iPod, iPhone screens on MAC or PC. The devices connect wirelessly to proceed with further functions.

7. Conformance Testing

Conformance/compliance testing is a type of testing which is performed to validate if the application is meeting the Market place and Enterprise policy guidelines. It is like an audit done to check whether certain standards are being met or not. Conformance Testing is focused on two main areas- App store guidelines and Enterprise policy compliance. Each Market place has their own guidelines. We need to validate if the application is following the guidelines of each of these app stores.

1. App store Guidelines pertaining to User Interface, Media Content, Privacy, Spyware and Phishing, nudity, religion, culture, violence, etc.

2. Enterprise Policy Compliance pertaining to a different set of industrial standards. For eg: For the pharmaceutical industry, the Food and Drug Administration (FDA) passed rule comes into the picture, For the pharmaceutical industry, the Food and Drug Administration (FDA) passed rule comes into the picture, In healthcare, the Health Insurance Portability and Accountability Act (HIPAA) includes an administrative simplification section, which mandates protecting the information assets of patients. So, it is a dire need for the testing organizations to follow the necessary guidelines and compliances to limit the risk that non-compliance might follow.

Reap the benefits of different types of testing

In this day and age, mobile app quality matters the most as the market is very competitive. We need to focus on user experience as well as the performance of the app. If the app contains bugs the app ratings will go down and so will the number of app downloads. If we can make our app bug free than the chances of app gaining popularity will increase. This can be achieved by performing different types of testing on the mobile application. In the next blog in this series, we will talk about mobile app testing strategies.

Want to test your Mobile App?

Join pCloudy Platform!

Signup for Free



Watch this video for more information:

Related Articles:

App Testing with AI and DevOps


Are we not living in an amazing time? Technologically advanced, digitally sound!



We thrive on all things digital. The world around us is becoming all digital with limitless possibilities. Today as a consumer, you can preorder your coffee, interact with augmented reality in the store, and skip the lines at store with alternative payment methods.



To cut the story short, as a consumer, we have access to unlimited goods and services and connected around us. And mobile is at the center of all this change. It’s the tool that is bridging the gap between the digital and physical.



And the availability of 5 million apps come as a proof of this explosion. In the first quarter of 2018, Apple had 2 million apps on App store. As of the same quarter, Android users were able to choose between 3.8 million apps. More and more businesses are adopting Mobile Apps as their primary channel for business growth. This explosion proves that mobile is at the core of customer experience.



Before moving further into the topic, you can watch the entire webinar here or else you can skip the video and continue reading to get the gist of the webinar.




As a business mobile Apps are not just another channel. More and more organization are realizing that it can be a means to create awesome customer experiences. There are numerous examples to illustrate.



One such example is Starbucks.

The secret to Starbucks’ app’s success is that it gives users an intuitive experience, making it as easy to find a store, order your coffee and make a payment through their wallet. Recently, Starbucks has also taken the mobile app experience one step further with an innovative conversational ordering system powered by Artificial Intelligence (AI). The explosion in mobile apps imply to speed. How quickly you can make a change and let the customer experience it? The mathematics of velocity matter here. Market speed has left companies with a simple problem: How do we go faster than we ever have before, without losing an eye on quality?


The success stories like Facebook and Netflix tell us that we can
It is an amazing fact that Facebook mobile app is updated and refreshed every two weeks like clockwork. That’s the new normal. We will talk about this example in detail a little later in the webinar.



So in order to gain Quality@Speed, we reach to a point where experience and quality intersect and we name this convergence Quality@Speed. It’s a no brainer to say that Quality @ speed can be achieved with two fundamental principles.



Agile: Agility allows teams to work closely with business and it Pulls quality forward. It’s also called Shift Left of Quality. You are delivering small chunks to end consumers on weekly or monthly basis. This allows teams to get feedback early on.



DevOps: DevOps brings you speed. It’s a Shift left of operations.



Shift left of operations



DevOps practices allow you to create “ready to deploy code” on demand. In other words, it means deploying software and the environment on which it runs, automatically and on demand, at any stage of the software delivery lifecycle. You can truly have multiple deployment in a day.



If we dig deeper, DevOps is enabled by two practices Continuous Integration and Continuous Delivery. These two will not work in sync until you have continuous testing in place. It’s also proven by many independent studies.



Here, we have a look at the data extracted from World Quality report, 2017-18 showcasing the popular and the best practices followed in DevOps.



World Quality report 2017-18



If we have a closer look at the data, we will find that 87% of CIOs and senior tech professionals use or are planning to use cloud based test environment. Depending on choice of organization, it could a Private or public cloud but it’s a must to achieve speed.



Second data point is about Continuous Testing, here as well more than 80% of respondents chose this as a preferred DevOps practice.


Let’s look at what some of the success stories say


Facebook follows Ship early and Ship often approach. They update their web app multiple times a day while their Mobile Apps with frequency of almost 2 weeks. This is possible with DevOps best practices they have been following from past few years.



DevOps at Facebook



If we analyze their DevOps story in short, we find that one of the biggest takeaway for Mobile Teams is their massive investment in device infrastructure. Every time they make a change to app, it gets tested on 2000 real devices. Imagine 2000 real devices! They have bypassed use of simulators or emulators.


Mobile DevOps Challenges
Now let us move on to have a look at some of the Mobile DevOps challenges that comes as an obstacle on the way of mobility teams.


Multi-platform Support
Mobile apps have multi environmental target. Mobile apps have to deal with device fragmentation as they need to be workable on multiple devices. This poses a test for Ops team to build an optimal device infrastructure. Moreover, it is difficult to keep pace with the ever changing device requirements.


Mobile apps as an enterprise front end
Mobile apps, that too, mostly the enterprise mobile apps catering to business-to-consumer (B2C) or business-to-employee (B2E) segment of apps, characteristically have very less trade logic on the mobile device itself. On the other hand, a B2C or a B2E mobile app
serves as a front end to enterprise mobility already in use by the firm, such as transaction processing systems, employee HR systems, or customer acquisition systems.



This implies that the mobile app, available on multiple platforms as a native or Mobile Web app, needs to be built and delivered aligned with the backend services. The biggest challenge for DevOps is to think about enterprise mobility holistically and manage their build and release processes and cycles.


The App store
The app store includes an extra asynchronous step to the deployment procedure since developers are not able to update apps on demand. Even for grave bug fixes, new app versions need to pass through an app store submission and review process. Continuous delivery here gets a roadblock and the instant delivery becomes “submit and wait.”


Build Challenges
Since apps today are supported on multiple platforms, numerous different builds of the app has to be triggered each time when a change is being deployed by a developer.



The build system and configuration for each supported mobile environment is dissimilar from the others. You will probably require a small farm of build servers to be provisioned and available to manage these multiple operating system builds.


A typical Mobile DevOps Architecture
Let’s try to depict the Mobile DevOps cycle. Some of the tools mentioned here are a representative set of tools in the respective category.



Mobile DevOps cycle



It starts with a Dev checking in a code to Git/Versioning system. That triggers the CI server to build the App which could be Internal build server or a cloud system like Circle CI. Once the build is successful, Unit tests are runs on Real devices. If the Tests are pass, build is pushed to QA Env. Where Automated regression tests are triggered on real devices. If that’s a pass App compatibility tests for new features are done.


The Evolution


DevOps Tools



We’ve by now witnessed quite a journey to reach Continuous Testing. “Classical” testing was intended for software delivery cycles spanning months or year. Agile has changed this norm to a 2-week development iterations—but now something extra is required to meet today’s insatiable demand for software. Attempts to fasten the process further, created a chasm between Development, Test, and Operations. That gap has been bridged with DevOps and Continuous Testing in order to move beyond that speeding up plateau. However, when we look into the future, it’s clear that even Continuous Testing will not be enough. We need “Digital Testing” to achieve extra acceleration and meet the quality needs of future. AI can help us get there.


Mobile Testing and AI

If you keep pace with the market buzz you will find there is an ongoing debate about what AI can do? When it comes to testing, lot of theories have started predicting that AI has the ability to replace testing. Well personally I don’t see this happening in near future. But we certainly are very excited about capabilities AI present in from of us.


When we an organization think of using AI to sole testing problems we think on three lines
a) Can it improve speed of current testing process?
b) Can it help generate meaning full data for me to make intelligent decisions?
c) Can it improve the test coverage and reduce cost?



So, are you ready to adapt a personal assistant for testing. So are you ready to say? Certifaya, Can you run an App Test for me? pCloudy’s AI powered bot, can automatically test the mobile applications over hundreds of real mobile devices and gives its users real time insights into the app’s behaviour and performance. Do you want to explore more? Try Certifaya for free now and testify it yourself. You can also go through our webinar on the same topic to understand it in detail.



Monitoring Mobile App Performance



Mobile Device App Testing
Source: Pixabay

With the myriad of apps cluttering our smartphone screens nowadays, it has become all the more important to optimize app performance. While going through your daily routine, you certainly don’t want useful apps hanging up or worse still, crashing abysmally.



In this post, you’ll know how app monitoring performance works so that you can get the best out of your smartphone software.



What is application performance management? 10 APM features that we can tick right off our fingers are:

  • Troubleshooting of disruption of frequent speed and uptime
  • Monitoring of the speed at which transactions are performed by end-users and systems
  • Use of a single integrated suite of software tools
  • Load-testing
  • Synthetic monitoring
  • Real-use monitoring
  • Root-cause analysis
  • Web-performance monitoring, to gauge app speed and uptime
  • An end-to-end overview of bottlenecks
  • Review of service interruptions

APM is integrated through the lifecycle of an application including the pre-deployment and post-deployment stages. It is therefore important for developers, testers, and business teams.
A slow load can be prevalent due to a host of issues related to APIs, servers, or browsers. APM techniques are what help pinpoint the actual problem.



Basic availability monitoring involves testing IP protocols and network services, but a user needs to establish some optimal performance thresholds and real-time alerts to monitor and manage both speed and reliability.



Tips for monitoring app performance

Tips for monitoring app performance
Source: Pixabay

Performance monitoring must take into account certain things in order to optimize user experience. These include measuring from the user’s point of view, i.e. performance, stability, and resource utilization in real time the way the user perceives them.



The context is crucial too. It’s important to determine how many users were affected by a slowdown, and what action on a specific operating device prompted the disruption. To truly experience a ‘mobile moment,’ you should follow these tips for monitoring your app performance:



Measure Frame rendering time

Only measuring network time doesn’t cut it out for users, who are interested in when the network resumes as well as when it responds.

Measuring response time by the device or operating system allows the product manager to focus on one platform at a time, respond to performance issues, and deploy resources accordingly.



Measure battery usage

It’s crucial to measure the battery consumption of your mobile app, along with data plan impact and memory usage. If the app is responsible for draining your battery, you should bring it in line with best practices.

Frequent updates can also be minimized so that user satisfaction can be increased.



Measure cell data consumption

Recent studies by Dimensional Research have shown that 20% of respondents stopped using apps that were heavy on data usage. This indicates that you should measure the consumption by app version, the total number of users, KBs of data consumed per minute, the amount of data being transferred per hit, and the percentage of data being consumed per hit.



Measure errors

HTTP errors from certain URLs need to be captured. This will help track the number of users who received an error, the actions that resulted in it, number of users with errors on app launch, the percentage of actions that led to at least one error, and the app version.

Priyanka Charak | Posted on | 2 min Read

Problems in Mobile App Testing


Mobile market has shown a phenomenal growth over the years and guess who is responsible for such tremendous success- undoubtedly, it is the mobile application market and evidently its progress appears to be indomitable even in coming years. As per the research, mobile applications are expected to generate around 189 Billion USD revenue figure by 2020 merely by means of app stores and in-app advertising.. As this stream of Mobile application gets strengthened, the competition to make each app unique and effective grows even stronger. The real challenge is to maintain the competitiveness by keeping up with this fast changing industry. With so many variations in the mobile devices, it becomes a challenge in the mobile app testing to succeed in ‘All-Device’ scenario.



Here are the most common challenges faced in the mobile application testing:



1. Multiple Devices
2. Networks
3. Choice of tools
4. Screen Sizes
5. Types of Mobile Apps
6. AI Test Automation



1. Multiple Devices: As the mobile market is growing, it’s coming up with more advanced features that before. This becomes a challenge when mobile apps are incompatible with different Operating systems. A mobile app that runs smoothly in one OS might not work well in the other operating system and in different versions of it.



Android OS Distribution



2. Networks: This factor has the most impact on the performance of the mobile application which effects the experience of the app even more. The Wi-Fi speeds, signal strengths or the network drops can cause a bad taste in the mouth of the end user. Since all the network carriers are supporting different data volumes, it is important to test the bandwidth usage. A mobile app tester has to consider all these factors and ensure the app runs smoothly on all networks.Testing on real networks is a fundamental practice to check the existent challenges of testing. In order to cater to this situation, pCloudy offers such a testing environment where the user can test their apps on different network conditions on real mobile devices on cloud.



network-simulation-tool



3. Choice of tools: Testing is the vital aspect of Mobile App Development life Cycle and there are myriads of tools available in the market. pCloudy offers access to tools like Espresso, Appium, Selenium, OpKey, Calabash, Jenkins and many more. Choosing the right tool as per the requirement is the most important decision. The efficacy of MAT process would completely depend upon the competency of the Test-automation tool.



Things to consider before tool evaluation:

  • Type of apps: Apps can be native, hybrid or web. While the trend is inclined towards hybrid apps but the tool of choice should be competent enough to support other kinds of apps.
  • Cloud Testing: Implementing a test automation cloud empowers teams to perform testing on any automation external testing framework .Moreover, the test results can be accessed from any location worldwide.
  • OS Support: Most of the apps are developed for IOS and Android but the scope can expand to Windows, Firefox OS, etc., anytime as the customer base increases. So, the automation tool should be able to support all platforms.



Frameworks



4. Screen Sizes: There are numerous devices-Android or IOS, available with different screen sizes. It is quite a challenge to test for each screen size. IOS mobile app developers who mostly focus on pixel perfect screen design now have to focus more on adaptive without changing all necessary screen elements. So, the businesses have no choice but to change their mobile app design as per the screen size of the devices to offer a top- notch user experience.



webdev



5. Types of Mobile Apps: Mobile apps can be based on either of these three architectures-native , hybrid or web application. All these types have different test case scenarios, and have different app behavior from installation to functionality.The decision of how the app will be tested depends on all these aspects.



Native Hybrid Apps



6. AI Test Automation: AI testing automation has become a vital part of the testing world and is the future of automated app testing. AI Bots can create test cases automatically, generate test codes etc., just by defining a specific testing goal and by providing the initial stage inputs. People still believe in traditional test approach without encouraging and believing testing by Bots at the times when Automated AI testing bots are the Golden Key to MAT automation success.



A good mobile app testing strategy would include a right mix of testing on real devices, user testing and bot testing all at a single platform.



pCloudy provides a biggest cloud platform for automated and manual testing of mobile apps on real devices. It has its own cluster of real devices hosted on cloud to test IOS and Android Apps. Visit pCloudy to choose your plan for availing the best MAT services.

Priyanka Charak | Posted on | 2 min Read

App Testing Companies Must Follow



Today, the world is earnestly dependent on mobility devices and so is their dependency on the mobile applications. The number of smartphone users are expected to reach 3 billion by 2019 out of which India alone covers half a million. So, it becomes impertinent to have an extremely practical mobile application strategy to make the usage of it more effective. Unless the mobile application is acceptable and extremely compelling to the users, it becomes inconsequential to even trade in it. So, there is a huge responsibility on the shoulders of Mobile application companies to assure the accessibility, security, purpose and usability of the mobile application to make it noticeable and engaging enough in long term.



pCloudy is fully equipped cloud based platform with a strong principled approach to tackle and heed the performance of today’s robust mobile applications. Following are the 5 best practices to count on for successful mobile app testing:



1. Master Plan
2. Device Testing
3. An early stage testing move
4. Crowd Sourced App Testing
5. Automation



1. Master Plan: A common plan is what will drive the team towards the ultimate business goal. Defining the testing approach, the effort, the timeline and the expected results would solve a lot of anticipated problems in different testing phases.



2. Device Testing: Some important points in context to devices are:

  • Testing on every possible device is what looks promising but is impossible. So, testers have to be smart and cover the largest market with largest sample size.
  • Testing on real devices is what is going to be the reality check and is going to give a better idea of the challenges and the convenience of the general usability of the app.
  • Test on more than one OS version to check interface compatibility and consistency.



5 Best Practices App Testing



3. An early stage testing move: Testing early ensures quality and makes the application more favorable in the market as per the new approaches in mobile application development. To minimize the defects at later stages, testing efforts should start at the early stages of mobile app development life cycle.



mobile app development life cycle



4. Crowd Sourced App Testing: The best platform to employ the benefits of cloud which allows global pool of experts from all over the world to be utilized for incomparable testing practices and performance saving both time and money.Not to be considered as a replacement of traditional testing but it has some obvious benefits of testing in real world conditions and without investing in full-time testers. With more participation,feedback and reporting actions, crowd testing has become a reliable and most sought practice today. With the help of pCloudy’s global crowd, testing has become an easy ballgame ensuring app testing in different environments with different network bandwidth, on different devices and on time delivery.



crowd source



5. Automation: Test Automation is what a machine does much faster and with less error than humans. This approach would save a lot of time, cost and would provide great return on investment but for reaping all these benefits, this has to be properly planned as it involves good investment, training and cost of trained resources and tools.If the objectives are undefined, it can lead to wastage of time and resources.



Mobile app testing is facing challenges in terms of changes in networks, operating systems and of course devices. So, the functioning and performance of the mobile applications becomes the prime focus. Selecting the best tool and the reason of doing so is very important. A strategy with clear objectives would be an informed move and a savior in this decision making process.



In the end, all we have to keep in mind is the user is happy using the app and is able to fulfil the purpose. All of this cannot be achieved by an individual but by the effort and strength of the team of both Developers and testers. There can always be brainstorming and learning from failures but the real game can be played by having a strong unified strategy.



pCloudy is a market leader in mobile app testing providing a wide range of MAT services. It has the most powerful mobile app testing platform which gives you a chance to access to real Android and IOS devices in a single click. Connect with our expert team to build a customized MAT strategy for your mobile application.

pCloudy 5.0



pCloudy is a unified mobile app testing platform which is trusted by its users for its excellent performance. We have more than 30,000 users across the globe, and we have received an overwhelming response for our platform. From bot testing to crowd testing, pCloudy has always been a front runner in the market. And with the launch of pCloudy 5.0, we are up for the challenge once again. It is a re-imagined and re-worked upon platform created in-line with intelligence to meet the market demands and accelerate delivery.



Let us have a look at what’s new here:







Features



a. iOS Connect
b. Automation Studio
c. Follow Me



a) iOS Connect: One of the very powerful features that we added is the iOS Connect. The major challenge iOS developers had been facing was the debugging of their iOS apps because of the difficult Apple guidelines regarding building any utility . We are proud to say that we have been successful in cracking that.
With iOS Connect, you can connect to an iOS Device which is present remotely and access the device as if the device is connected to your computer. With iOS Connect we are bridging the gap for the iOS development life cycle.



iOS Connect



b) Automation Studio: It is another promising feature that can revolutionize mobile app automation. We now have an in-built automation studio in pCloudy platform where you can access the devices to record your test scripts and execute it in parallel on multiple devices without writing any code.



There’s something more to it! If you already have your projects on Appium you can record your new workflows and export it to Appium Java format. This new integration would not only enable every user to start creating Automation scripts but it will also help Appium users to speed up their Automation. This makes pCloudy truly a Unified app testing platform.



Automation Studio Launch



c) Follow me: It is again one of the ‘wow’ features of pCloudy 5.0. This feature can speed up your App Testing exponentially. Follow me allows you to test your apps on 3 unique device while performing your test on only 1 device, thus saving your testing time multi-folds.



Follow Me



Re-Imagined UI



It has been designed to give a leaner, simpler and faster user experience. The look and feel of the pCloudy platform has been transformed keeping in mind the requirements, usability and ease of our users. All the pages have been made more intuitive. To simplify, we have grouped the actions together to save your time in figuring out the next step.



a. True Collaboration
b. Global File Storage
c. Comprehensive reports at a single stop
d. Test Scheduler



a) True Collaboration: We have introduced a powerful feature on our revamped Device Interaction page. Now, you can take the screenshot of the action you are performing and see the screenshot next to the device. But, the icing on the cake is that you can edit the screenshot, save it and log a bug directly to the JIRA enabling true collaboration between the developers and testers.



UI Design



b) Global File Storage: Heeding to the demands of our users we have reduced the clicks to perform any action on the File browsing /storage page. The file uploaded once will be available across all the different locations we have. It will also allow sharing of files across teams.



Global File Storage



c) Comprehensive reports at a single stop: Now, to make the user experience simpler and faster, we have placed all your reports at single stop be it manual or automation across all locations. Not just that, you can see all reports in the same format with much detailed information. Raising bugs after analyzing reports is also possible from here.



comprehensive-reports-at-a-single-stop



d) Test Scheduler: We have re-designed this page based on a Guided interface where the interactions are more thoughtful, straightforward, and guide you to the next step. It needs zero learning to run automation scripts on multiple devices.



Test Scheduler



pCloudy 5.0 is another breakthrough for us. After launching pCloudy 5.0, it is time to get feedback on a larger scale. We’re going to continue improving the UI, the navigation, and add some futuristic features to make your app testing simpler and faster. While we do that, we’d love to continue getting feedback.

pCloudy Platform


This article explains the options available on device page. These options will help you use the devices effectively on pCloudy platform. pCloudy is a feature rich platform and supports whole lot of features to ease your device interaction. There are many single click options to speed up your testing on devices. On connecting to a device, You will see many icons in the top pane.

Lets understand what each of these icons/features does for you.



Device icons



1.
Camera

Capture high resolution screen shots with the skin of the device

2.
landscape and portrait devices

Change the orientation of the device to Landscape and portrait

3.
Cross Browser Testing

Open the browser from the list of preinstalled browsers

4.
Keyboard

Use the extended keyboard if you want to enter some text on the device. However, for Android ver 5.0 and above you can directly enter the text from your system keyboard

5.
Battery

Check the stack trace (crash logs) if the application is crashed

6.
Cursor
Navigate the application with the buttons
7.
zoom in zoom out

Zoom in/out the device shown on the screen

8.
zoom default icon
Reset the zoom level to bring the device to default size
9.
re-connect to a device

Click to Re-connect if the device shows black screen

10.
Extend Device Session

Extend the session if the device is available

11.
Wake Up

Wake up the device from sleep mode or push the device to sleep mode

12.
Stop Device Session
Release the device back to the cloud



pCloudy’s Device Settings tab has lot of commonly used features and device interactions. Some of the key features to test are Network, Location and Audio.

Lets see those in details.



mobile device settings

1.
Reboot Device
Reboot the device remotely
2.
Toggle Wifi

Switch ON/OFF wifi

3.
Adjust Volume
Adjust the device volume
4.
Manage Apps

Manage your apps on the device

5.
Network Profile

Throttle network to simulate different network conditions

6.
add google account
Add Google account
7.
Set Phone Location

Teleport the device – Set any location of the earth on the device

8.
Settings

Open Device settings on the device

9.
Open play store on mobile device

Open play store on the device

10.
open developer options on website

Open developer options on the device

11.
Inject Audio

Send audio commands to the device for testing applications which supports audio commands
